SUPERWINCH H9W HYDRAULIC WINCH (ON WINCH BUMPER )

Description:

SUPERWINCH H9W HYDRAULIC WINCH

IN USED CONDITION

GOOD WORKING ORDER

WHAT YOU SEE IN THE PHOTO IS WHAT YOU GET

CAME OF A 4X4 OFF ROADER



The Superwinch H9W - heavy duty, high quality worm drive hydraulic winch, engineered to ensure total reliability during recovery & winching operations. Designed to perform in a wide range of applications. Compact size and robust construction. Heavy duty, steel centered aluminum bronze worm wheel gearbox and casehardened precision ground worm for optimum reliability. Worm set brake for substantial backdrive resistance. Rugged, high torque motor with proven reliability. Free spooling manual release for rapid rope pay out. Heavy duty fabricated steel drum assembly mounted on maintenance-free plain bearings. Centre PTO Hydraulic Pump Power Take Off hydraulic pump control unit, hydraulic pipes and oil tank

For optional extras on this winch please put H9W in the search bar

Specifications
Rated Line Pull 9,000 lbs (4,080 kgs), 40kn
Motor High Torque
Gearing Worm & Worm-wheel Drive - Gear Ratio 54:1
Maximum Oil Pressure 1800 psi (BAR 124) 126.58 kg/cm
Maximum Oil Flow 12 gpm (45 l/min)
Clutch Free-Spooling Clutch - Manual Release
Brake Worm Set, Back-Drive Resistance
Wire Rope 3/8" x 100' (10mm x 30m)
Dimensions 16.3” L x 15.2” D x 8” H (414mm L x 386mm D x 205mm H)
Drum Diameter 3.0" (76mm)
Drum Length 8.75” (222.75mm)
Mounting Bolt Pattern Side, foot, angle, flatbed, or low mounted
Installed Weight 63 lbs (28.5 kgs) without wire rope and fairlead
Line Speed 16 FPM
