IU0U Automatic charger for cars, boats, & Campers

Description:

WAECO PerfectCharge MCA 1215
6-stage IU0U automatic charger 15 A
Charging of 1 battery + starter battery

Charge outputs: 1 + 1
Input voltage range: 207 - 253 volts AC/50 - 60 Hz
End-of-charging voltage: 14.4 - 14.7 volts DC
Float charging voltage: 13.8 volts DC
Recommended battery capacity: 40 - 170 Ah
U0 phase limited at: 8 h or 16 h
Max. charging current: 15 A
Operating temperature: -20 °C to +50 °C
System: 6-stage charging characteristics, overload/short-circuit protection, Sleep mode using the remote control or dip switch on the device, type of protection equivalent to IP 21
Dimensions (WxHxD): 179 x 63 x 238 mm
Weight: approx. 1.6 kg
Test mark: CE, e-certified (Automotive EMC Directive)
Item designation: PerfectCharge MCA 1215, 15 A
Ref. No.: 9102500027
Item designation: PerfectCharge MCA 1215, 15 A (UK version)
Ref. No.: 9102500046
Accessories Remote control MCA-RC1
Ref. No.: 9102500037
PerfectControl MPC 01,
Intelligent battery management system
Ref. No.: 9102500041
Hella Sensor MCA-HS1 battery sensor
Ref. No.: 9102500038
Temperature sensor MCA-TS1
Ref. No.: 9102500036
