B2 Audio quota mk I 1000W RMS

Description:

Underated rms ratings. Was running around 1400w rms at 1ohm. £150


Circuit Configuration
Frequency Response
Signal to Noise Ratio
Input Sensitivity
Input Level Selector
Crossover
Low Pass Crossover Range
Subsonic Crossover
Bass Boost
Variable Bass Boost Range : 35Hz ~ 100Hz
Remote Control
Damping Factor
Power Terminal gauge
Fuse Rating

Quota
HI-EF Class D Mono
: 15Hz ~ 280Hz
: 90dB
: 6V ~ 0.2V
: -
: 12dB / Oct

: 35Hz ~ 250Hz
: 35Hz
: 0 ~ 9dB
:
: 250
: 4 ga
: 90A

All features are subject to change in the continuing effort to improve the products without notice.
Quota Power @ 4 Power @ 2 Power @ 1 (14,4V @ 1% THD)
400 W x 1 650 W x 1 1000 W x 1
Specifications (detailed)
2) The amplifier has a 4 stage advanced protection circuit;
-Thermal protection, Voltage sensors, DC offset & short circuitry via speaker outputs.
The Quota utulizes a double sided SMD pcb & high current mosfet switching devices in both
the in- and output stage.
A

4) wired remote level control is optional for the amplifier. - This unit will enable remote gain adjustment.
- For more advanced features like selectable bass frequency, boost level & gain,
the Better Bass Remote (optional) can be used.
5) The crossovers of the Quota are variable 12 dB/octave filters for both low pass & subsonic.
